Specifcations
Transmission Type
2.4GHz
Poplar Pattern
Omnidirectional
Frequency Response
20Hz-16kHz
Signal-to-noise Ratio
80dB
Sensitivity
-42dB
Operating Range
50m (without obstacles)
RF Output Power
6dBm
Charging Port
USB-C
Transmitter's Battery Capacity
95mAh
Transmitter's Charging Time
Approx. 2 hours
Transmitter's Battery Life
Approx. 9 hours
Receiver's Power Requirement
Supplied by External Devices
Weight
BY-V1-TX/ BY-V2-TX:9.5g; BY-V1-RX/ BY-V2-RX:6g
Dimensions
BY-V1-TX/ BY-V2-TX:52.22×25.23×19.75mm; BY-V1-RX/ BY-V2-RX:43.92×23.5×9.3mm
Packing List
BY-V2-TX Transmitter ×2
BY-V2-RX Receiver ×1
USB-C Charging Cable ×2
Foam Windscreen ×2
